PEROLO 3" 30° NEATFLOW FOOT VALVE MK2
PEROLO 3" 30° NEATFLOW FOOT VALVE MK2

Our Price: $1,331.68


Product Code: FVNF300B-30D-SS-01
Qty:

Description Technical Specs Sheet Information

MPN NF33AX1

The 3” NEATFLOW™ foot valve (30° or 45°) is designed for use on tank containers, road tankers, rail tank cars and static tanks for loading and unloading liquids while preventing any risk of leakage.
Features
• Inlet flange angled at 45°
• Full 316L stainless steel construction.
• Inlet flange: 8 holes with14mm diameter on a PCD of 178mm.
• Valve mechanism outside of the tank.
• Shear groove breaking system.
• Side operated handle.
• Design temperature: -40°C +190°C.
• Weight: 8.5kg.
• Working pressure: 4 bar.
• Test pressure: 6 bar.
• Congealed/crystallized cargo adapted poppet option available
• Heating box option available.
• Remote control lever option available
• Fusible link option available
• Extended pipe option available
• Custom flange drillings available
• Rounded outlet flange option available
• AAR sealing option available
• HALAR® coating and HASTELLOY® insert options available for very corrosive products.
• Conforms to IMDG, ADR and RID standards
• Bureau Veritas approved
